Speacial Features

* Multi parameter of 4 to 6 items(pH(ORP/mV), EC, Residual Chlorine, Turbidity
   and Temperature
* Auto Calibration of pH, Conductivity according to user's setting
* User can select items to be measured that requsted from site
* Real time controlling and monitoring
* Reducing labor and management cost
* Self Diagnosis system
* Economic operation and maintenance
* Remote control & Monitoring using wireless transmitter

Specifications

Items	pH(ORP/mV)	EC(TDS/Salinity)	Residual Chlorine	Turbidity	Temp
Measurement Method	By Ion sensor	By Ion Sensor	Polarographic Mehtod	Light Scattering at 90 Degrees	RTD, NTC Sensor
Sensor Type	Gel with visible KCl reserves	2-ring platinum (Shaft material: Plastic)	Gas Transmittal Sensor	Visible	RTD NTC
Range	0.0 ~ 14.0	0.05~200mS/㎝	0~3mg/L	0~10/1000 NTU	-10~55℃
Repeatability	0.03pH	0.1 ms/㎝	±2%	± 1% of Reading	±2%
Resolution	± 0.01pH	± 0.5%	-	2%: 0~ 40NTU 5%:40~100NTU	±0.4℃
Calibration	Automatic		Free Calibration	Automatic
Condition of sample	Quantity is 0.5 to 3.0 L/min. Each temperature should be 5 to 40℃
Installation	Indoor or Outdoor installation available
Data record	Hard Disk & Printer
Power Supply	AC 110V/220V(50/60Hz)
Power Consumption	800W
Output	4~20mV(Option: RS232C/RS485, Internet, LAN(TCP/IP), Wireless(Cell phone)
Measuring Cycle	Continuous measuring and Measuring cycle setting up classified by item.
Sample	Auto Pumping or gravity/ Auto water supplying type
Application	Drinking water, Process water, Utility water
Dimension	1600 x 650 x 750 (H x W x D)
